SOLUTIONS FOR CARDIO / VASCULAR IMAGING
SOLUTIONS FOR CARDIO / VASCULAR IMAGING
Based on the most successful Cardio/Vascular X-ray imaging chain in the market Dunlee provides a variety of product bundles at different power levels ideally suited for high performance interventional systems.
Every product bundle is available as dedicated Cardio or Vascular version. It comprises an X-ray tube assembly, generator, cooling unit, high voltage connections and a sophisticated service concept to keep service costs and downtime of your system down.
Dunlee product bundles for Cardio/Vascular stand for
Excellent image quality at low dose
- Fast Pulses by Grid Switch Electronics embedded in Tube Housing (optional)
- State of the art microprocessor controlled generator providing high-precise dose control
Outstanding reliability
- Fast cooling by metal-lubricated Spiral Groove Bearing Tube
- Full metal ceramic tube insert designed for extreme low arcing rate
- Advanced thermal modelling integrated in generator to protect tube overload
Advanced Serviceability
- Modular subunit architecture with only 11 field replaceable units
- Sophisticated tools for easy and fast fault finding
- Automatic tube adaptation (optional).
| Key Specifications | |
|---|---|
| Max Generator Power (kW) | 80-100 |
| Emission current (mA) | 10-1,000 |
| Exposure time (ms) | 1-16,000 |
| Max Tube Voltage (kVp) | 125 |
| Cardio Version | |
| Focal spot size | 0.5/0.8 |
| Load capability (kW) | 45/85 |
| Anode Angle Cardio | 9 ° |
| Vascular version | |
| Focal spot size | 0.4/0.7 |
| Load capability (kW) | 30/65 |
| Anode Angle Vascular | 11° |
| Max effective assembly heat storage | 5.4 MHU |
